- Using copeland GLZB15KQE-TF
- R404a
- Single-phase
- 240V/50HZ, 10 amp
Specifications:
- Power Supply: 1P/240v/50HZ
- Horse Powers: 2HP
- Compressor: GLZB15KQE Maximum current 6.0AMP
- Fan Voltage: 1P/240v/50HZ
- Fan Current: .5AMP
- Fan Power: 166W
- Fan Rev: 910R/MIN
- Suction Line: 19SAE
- Liquid Line: 9.5SAE
- Size: W1040 x D570 X H700MM
Includes:
- Evaporator: GLCS21/230M 220V/10AMP for +2C
- Expansion Valve: TES2 with 03 expansion valves
- Control Box: 2HP - 220V/50HZ
Warranty: 12 months labor, 24 months parts
