- Using copeland GLZB29KQE-TFD
- R404a
- Single-phase
- 240V/50HZ, 15 amp
Specifications:
- Power Supply: 1P/240v/50HZ
- Horse Powers: 4HP
- Compressor: GLZB29KQE Maximum current 11.0AMP
- Fan Voltage: 1P/240v/50HZ
- Fan Current: 1AMP
- Fan Power: 166x2W
- Fan Rev: 910R/MIN
- Suction Line: 19SAE
- Liquid Line: 12.7SAE
- Size: W1040 x D570 X H1100MM
Includes:
- Evaporator: GLCS36/240M 240V/10AMP for +2C
- Expansion Valve: TES2 with 04 expansion valves
- Control Box: 4HP - 240V/50HZ
Warranty: 12 months labor, 24 months parts
