FEATURES:

• Body and tank stainless steel construction 18/10 AISI 304, 12/10 thick
• Completely automatic
• Control of the belt-towing system provided with a clutch system that in accidental case stops automatically the belt
• Upper and lower fixed washing system ( 60 °C )
• Upper and lower fixed rinsing system ( 85-90 °C )
• Rinse system with optimized consumption
• S.S. rinse and wash arms that can be disassembled and interchanged
• Double skin with thermic and acoustic insulation
• Drawing washing tanks with rounded edges; guarantee the highest hygiene
• STAINLESS STEEL self-draining inclined washing pumps
• The drain valve allows to automatically empty the tanks
• Counterbalanced door
• The “SERVICE” function allows programming the maintenance interventions
• Belt conveyor with stainless steel chain and roll in nylon for a silent sliding
• Frontal maintenance
• Entry and exit splash shield, that avoids water splashed and steam leakages
• Load and unload tables with a slanted bottom
• Entry and exit table for dishes support
• Start and Stop button in the entry-exit machine
• Rinse economizer
• Automatic tank loading
• Thermometers for automatic control temperatures of the wash- and rinse water
• Tank and pump filters
• Insulated Boiler

TUNNEL COMPOSITION:

• 1 Wash - wash arms: 4 upper + 4 lower
• 1 Rinse - rinse arms : 1 upper + 1 lower

FRONT PANEL COMPOSITION:

• Low tension keyboard drives
• A Digital display indicates the temperatures of different tanks Sequential visualization of inlet/washing/rinse water temperature
• Single visualization of the other temperatures through the push selector switch
• PCB-board programming according to the type of machine and to the customer’s demand
• Alerts and functions showed on a display
• Warning light indicating “door open "or absence of overflow (when present) Limit switch alarm
• Water-fail alarm (tank loading) Flux meter alarm (when present) Thermic relays alarm motors
• Signaling of various functions and cycles starting 5 – Rinse boiler filling at daily starting
• Speed selection push button or machine running with the motor drive off 7 – Drying push button and light (when present)
• Pre-rinse push button and light
• Auto timer push button and light (when present) 10 – Rinse light
• Flux meter light
• Basket entry light (when present) 13 – Washing tank water level light
• Programming of maintenance operations
• Storage of dishwasher’s total and partial working hours

SAFETY

• Adjustable and strong feet
• Emergency Pushbutton in entrance and exit of the machine
• Pressure switch protection for heating elements
• Thermic protection for wash pump
• Automatic stopping of conveyor in case of foreign bodies
• Low voltage control circuit (24V) for greater safety during work operation
• Dishes (Stop with End Micro-switch on the exit table)
• Door opening safety device
• Emergency Lamp

SPECIFICATION

• One automatic speed: 1,16 mt/m'
• Hour capacity: 2300 dishes/h
• Max dimensions for wash: 430 mm height - 625 mm width

ACCESSORIES:

• 1 generic basket
• 2 cutlery baskets

OPTIONAL:

• Drying tunnel
• Steam condenser
• Pressure pump
• Extension table (entry-exit)
• Heat recoverer
• Heat pump

Warranty: 12 months labor, 36 months parts
