Features:
- Body and tank in stainless steel construction 18/10 AISI 304,
- Tunnel composition:
- - 1 Pre-wash - wash arms : 3 upper + 1 lower
- - 1 Wash - wash arms : 3 upper + 2 lower
- - 1 Rinse - rinse arms : 1 upper + 1 lower
- Corner loading
- Completely automatic,
- Pre-washing (40C)
- Upper and lower fixed washing (60C)
- Upper and lower fixed rinsing (85-90C)
- Washing and rinsing arms in stainless steel constructions,
- easy disassembly and interchangeable,
- Double skin with thermic and acoustic insulation ;
- Slanted tank with rounded edges,
- Stainless steel auto draining washing pump,
- Counterbalanced door
- Front panel composition:
- - Main ON/OFF switch;
- - Start pushbutton
- - Stop Pushbutton
- - Emergency pushbutton
- - Machine ON indicator
- - Machine ready indicator
- Water protection
- Overload cutout indicator
- Frontal maintenance
- Automatic tank loading
- Rinse economizer
- Tank and pump filters
- Insulated Boiler
SAFETY
- Feet adjustable and strong
- Pressure-switch protection for Heating elements
- Thermic protection for washing pump
- Automatic stopping of pull-through in case of foreign bodies
- Low voltage control circuit (24V) for greater safety during work operation
- Dishes (Stop with End Micro-switch on the exit table)
- Door opening safety device
SPECIFICATIONS
- One automatic feed
- Speed 1,5 mt/m'
- Hour capacity: 2240 dishes/H
- Hour baskets production: 140
- Max dimensions for wash : 400 mm heigth - 500 mm width
- Basket dimensions: 500x500 mm
- Pre-washing pump : 1,1 kW
- Washing pump: 1,5 kW
- Tank heating : 9 kW (electric)
- Boiler heating: 18 kW (55c)
- Geared motor : 0,13 kW
- Total power: 29,6 kW (55c electric)
- Voltage 400V/3/50Hz
- Low-voltage control circuit 24V
- Cycle water consumption : 210 liters/h
- Hardness between 5 and 10F
- Rinsing water temperature: 85-90C
- Dimensions : 1765x815x h1645mm
- Noise: dB<70
- Net Weight : 290kg
Warranty: 12 months labor, 36 months parts
