Features:
- Body and tank in stainless steel construction 18/10 AISI 304
- *Tunnel composition:
- - 1 Pre-wash - wash arms : 3 upper + 1 lower
- - 1 Wash - wash arms: 4 upper + 2 lower
- - 1 Rinse - rinse arms : 1 upper + 1 lower
- Completely automatic
- *Corner loading
- Upper and lower fixed washing (60°C)
- Upper and lower fixed rinsing (85-90°C)
- Washing and rinsing arms in stainless steel constructions
- easy disassembly and interchangeable
- Double skin with thermic and acoustic insulation
- Slanted tank with rounded edges
- Stainless steel auto draining washing pump
- Counterbalanced door
- *Front panel composition:
- - Main ON/OFF switch;
- - Start pushbutton
- - Stop Pushbutton
- - Speed selector
- - Machine ON indicator
- - Machine ready indicator
- - Overload cutout indicator
- Water protection
- Frontal maintenance
- Automatic tank loading
- Thermometers for automatic control temperatures of the wash and rinse water
- Rinse economizer
- Tank and pump filters
- Insulated Boiler
SAFETY
- Adjustable and strong feet
- Pressure-switch protection for Heating elements
- Thermic protection for washing pump
- Automatic stopping of pull-through in case of foreign bodies
- Low voltage control circuit (24V) for greater safety during work operation
- Dishes (Stop with End Micro-switch on the exit table)
- Door opening safety device
SPECIFICATIONS
- Two automatic feed
- 1st Speed 1,080 mt/m'; 2nd speed 1,580 mt/m'
- Hour capacity: 2080/3040 dishes/H
- Hour baskets production: 130/190
- Max dimensions for wash : 420 mm height - 500 mm width
- Basket dimensions: 500x500 mm
- Pre-washing pump : 1,1 kW
- Washing pump: 2,2 kW
- Tank heating : 6 kW (electric-55°) 9 kW (electric-12°) 21 kg/h (steam)
- Boiler heating: 21 kW (55°) 27 kW (water 12°) (electric)
- 27 kg/h (55°) 45 kg/h (12°) (steam)
- Geared motor: 0,15 kW
- Total power: 30,45 kW (55° electric)
- 39,45 kW (12° electric)
- 48 kg/h (55° steam)
- 69 kg/h (12° steam)
- Voltage 400V/3/50Hz
- Low-voltage control circuit 24V
- Cycle water consumption : 320 liters/h
- Hardness between 5° and 10°F
- Rinsing water temperature: 85-90°C
- Dimensions : 2115x815x h1710mm
- Noise: dB<70
- Net Weight : 345kg
Warranty: 12 months labor, 36 months parts
